Stainless Steel Air Curtain 2000m³/h 230V for Energy Saving
Premium Products
Stainless Steel Air Curtain 2000m³/h 230V for Energy Saving
1
2
3
4
5
6
Place of Origin :Guangdong, China
Brand Name :Theodoor
MOQ :10
Price :$99
Operating voltage :230 VAC
Mounting type :Wall / Window Mount
Airflow :2000m³/h
Weight :10 KG
Fan type :Cross flow type
Material :Stainless steel cover
Control type :Manual or remote control
Length range :0.9m-2m
Fan speed :2-speed
Motor type :AC type
Power supply :220-240V/1Ph/50Hz
Input power :160-350W
Air volume :1400-3600m³/h
Air speed :10-12m/s
Noise level :≤57-61db
Contact Now
Product Description
Electric Door Air Curtains - The Comfortable Air Conditioning System, saving air conditioning energy and keep clean indoor.
#304 Stainless steel design
Fingerprint-free stainless steel body is durable, no deformation, no rust, easy to clean, bright as new. The air inlet panel has strong pressure resistance, compact structure save installation space.
Stronger air door, stable performance
Adopt high speed pure copper silicon steel motor, experiment test continuous operation more than 8000 hours without failure. Dynamic balanced fan wheels with ball bearings which is low noise and stable performance.
Easy operation, multi-site application
Two speeds controlled by the remote control or key switch. Suitable for most of the entrances of restaurants, shops, shopping stores, fresh food shops and other chain stores.
1) Remote control 2) Two speeds 3) Stainless steel cover
A5 Series Compact Air Curtain For Door
Specifications:
Model
Size (mm)
Input power
(W)
Air Volume
(m3/h)
Air
Speed
(m/s)
Noise
(db)
Net Weight
(Kg)
FM-3509A (SS)
900x175x195
160
1400
10-12
≤57
8
FM-3510A (SS)
1000x175x195
180
1600
≤58
9
FM-3512A (SS)
1200x175x195
200
1900
≤58
10
FM-3515A (SS)
1500x175x195
230
2500
≤59
11.5
FM-3518A (SS)
1800x175x195
300
3200
≤60
13.5
FM-3520A (SS)
2000x175x195
350
3600
≤61
15
Air Curtains Applications:
Theodoor Air curtain is installed above the entryway of store, restaurant, hotel…etc. It can effectively isolate convection indoor and outdoor and keep temperature and humidity. Especially used in the location with air-conditioner to keep indoor environment and save energy of refrigeration equipment. In addition, Air Curtain can prevent the invasion of dust, pest and harmful fumes from outside. In this way, a comfortable indoor climate is maintained.
Commercial use
Supermarket, shopping malls, department store, small store, hotels, restaurants, hospital,
